| ： | EGG.3B.308.CYM |
|---|---|
| ： | Circular Connector Assemblies |
| ： | REDEL / LEMO |
| ： | CONN RCPT FMALE |
| ： | - |
| ： | Bulk |
| ： | 8 |
| ： | 1 |
1
$73.4000
$73.4000
10
$67.3600
$673.6000
25
$64.7700
$1,619.2500
50
$62.6100
$3,130.5000
100
$59.1500
$5,915.0000
| TYPE | DESCRIPTION |
| Mfr | REDEL / LEMO |
| Series | 3B |
| Package | Bulk |
| Product Status | ACTIVE |
| Connector Type | Receptacle, Female Sockets |
| Color | Silver |
| Current Rating (Amps) | 13A |
| Mounting Type | Panel Mount |
| Shielding | Shielded |
| Number of Positions | 8 |
| Orientation | G |
| Shell Size - Insert | 308 |
| Operating Temperature | -55°C ~ 250°C |
| Fastening Type | Push-Pull |
| Termination | Crimp |
| Ingress Protection | IP50 - Dust Protected |
| Material Flammability Rating | UL94 V-0 |
| Mounting Feature | Bulkhead - Rear Side Nut |
| Contact Material | Bronze |
| Contact Finish - Mating | Gold |
| Contact Finish Thickness - Mating | 59.0µin (1.50µm) |
| Shell Material | Brass |
| Shell Finish | Chrome |
| Insert Material | Polyetheretherketone (PEEK) |
| Primary Material | Metal |
